Voltage, Frequency and Plug Type of Single Phases Electricity of the World

The following is a complete overview of the voltage and frequency of all countries in the world and their respective plugs, sockets and household appliances. The table shows that in most countries, the mains voltage is between 220 and 240 volts (50 or 60 Hz); the number of countries operating at 100-127 volts is particularly small. In addition, Type A and Type C are the most commonly used electrical plugs in the world.

Single Phases Electricity of the World

In the table below, it can be noted that most countries and regions have clear plug and voltage standards. However, many countries in Latin America, Africa and Asia have different specifications-usually incompatible plugs, and sometimes the voltage varies from region to region. As a result, this makes it difficult for travelers to determine which plug adapters or transformers they need for travel.

Country/Area/City Single Phase Voltage Frequency
(Hz)
Plug type
Abu Dhabi 230 V 50 Hz G
Afghanistan 220 V 50 Hz C / F
Albania 230 V 50 Hz C / F
Algeria 230 V 50 Hz C / F
American Samoa 120 V 60 Hz A / B / F / I
Andorra 230 V 50 Hz C / F
Angola 220 V 50 Hz C
Anguilla 110 V 60 Hz A / B
Antigua and Barbuda 230 V 60 Hz A / B
Argentina 220 V 50 Hz C / I
Armenia 230 V 50 Hz C / F
Aruba 120 V 60 Hz A / B / F
Australia 230 V 50 Hz I
Austria 230 V 50 Hz C / F
Azerbaijan 220 V 50 Hz C / F
Azores 230 V 50 Hz B / C / F
Bahamas 120 V 60 Hz A / B
Bahrain 230 V 50 Hz G
Balearic Islands 230 V 50 Hz C / F
Bangladesh 220 V 50 Hz A / C / D / G / K
Barbados 115 V 50 Hz A / B
Belarus 220 V 50 Hz C / F
Belgium 230 V 50 Hz C / E
Belize 110 V 60 Hz A / B / G
220 V
Benin 220 V 50 Hz C / E
Bermuda 120 V 60 Hz A / B
Bhutan 230 V 50 Hz C / D / G
Bolivia 230 V 50 Hz A / C
Bonaire 127 V 50 Hz A / C
Bosnia and Herzegovina 230 V 50 Hz C / F
Botswana 230 V 50 Hz D / G
Brazil 127 V 60 Hz C / N
220 V
The British Virgin Islands 110 V 60 Hz A / B
Brunei 240 V 50 Hz G
Bulgaria 230 V 50 Hz C / F
Burkina Faso 220 V 50 Hz C / E
Myanmar (officially Myanmar) 230 V 50 Hz A / C / D / G / I
Burundi 220 V 50 Hz C / E
Cambodia 230 V 50 Hz A / C / G
Cameroon 220 V 50 Hz C / E
Canada 120 V 60 Hz A / B
Canary Islands 230 V 50 Hz C / E / F
Cape Verde (Portuguese: Cape   Verde) 230 V 50 Hz C / F
Cayman Islands 120 V 60 Hz A / B
Central African Republic 220 V 50 Hz C / E
Chad 220 V 50 Hz C / D / E / F
Channel Islands (Guernsey and   Jersey) 230 V 50 Hz C / G
Chile 220 V 50 Hz C / L
People’s Republic of China 220 V 50 Hz A / C / I
Christmas Island 230 V 50 Hz I
Cocos (Keeling) Islands 230 V 50 Hz I
Colombia 110 V 60 Hz A / B
Comoros 220 V 50 Hz C / E
Democratic Republic of the Congo   (Congo-Kinshasa) 220 V 50 Hz C / D / E
Republic of the Congo   (Congo-Brazzaville) 230 V 50 Hz C / E
Island 240 V 50 Hz I
Costa Rica 120 V 60 Hz A / B
Cote d’Ivoire (Ivory Coast) 220 V 50 Hz C / E
Croatia 230 V 50 Hz C / F
Cuba 110 V 60 Hz A / B / C / L
220 V
Curacao 127 V 50 Hz A / B
Cyprus 230 V 50 Hz G
Cyprus, North (unrecognized,   self-declared state) 230 V 50 Hz G
Czechia (Czech Republic) 230 V 50 Hz C / E
Denmark 230 V 50 Hz C / E / F / K
Djibouti 220 V 50 Hz C / E
Dominica 230 V 50 Hz D / G
Dominican Republic 120 V 60 Hz A / B / C
Dubai 230 V 50 Hz G
East Timor (East Timor) 220 V 50 Hz C / E / F / I
Ecuador 120 V 60 Hz A / B
Egypt 220 V 50 Hz C / F
Salvador 120 V 60 Hz A / B
United Kingdom 230 V 50 Hz G
Equatorial Guinea 220 V 50 Hz C / E
Eritrea 230 V 50 Hz C / L
Estonia 230 V 50 Hz C / F
Ethiopia 220 V 50 Hz C / F / G
Faroe Islands 230 V 50 Hz C / E / F / K
Falkland Islands 240 V 50 Hz G
Fiji 240 V 50 Hz I
Finland 230 V 50 Hz C / F
France 230 V 50 Hz C / E
French Guiana 220 V 50 Hz C / D / E
Gabon (Gabonese Republic) 220 V 50 Hz C
Gambia 230 V 50 Hz G
Gaza Strip (Gaza) 230 V 50 Hz C / H
Georgia 220 V 50 Hz C / F
Germany 230 V 50 Hz C / F
Ghana 230 V 50 Hz D / G
Gibraltar 230 V 50 Hz G
United Kingdom (GB) 230 V 50 Hz G
Greece 230 V 50 Hz C / F
Greenland 230 V 50 Hz C / E / F / K
Grenada 230 V 50 Hz G
Guadeloupe 230 V 50 Hz C / E
Guam 110 V 60 Hz A / B
Guatemala 120 V 60 Hz A / B
Guinea 220 V 50 Hz C / F / K
Guinea-Bissau 220 V 50 Hz C
Guyana 120 V 60 Hz A / B / D / G
240 V
Haiti 110 V 60 Hz A / B
Netherlands (officially the   Netherlands) 230 V 50 Hz C / F
Honduras 120 V 60 Hz A / B
Hong Kong 220 V 50 Hz G
Hungary 230 V 50 Hz C / F
Iceland 230 V 50 Hz C / F
India 230 V 50 Hz C / D / M
Indonesia 230 V 50 Hz C / F
Iran 230 V 50 Hz C / F
Iraq 230 V 50 Hz C / D / G
Ireland (Ireland) 230 V 50 Hz G
Ireland, North 230 V 50 Hz G
Isle of Man 230 V 50 Hz C / G
Israel 230 V 50 Hz C / H
Italy 230 V 50 Hz C / F / L
Jamaica 110 V 50 Hz A / B
Japan 100 V 50 Hz / 60 Hz A / B
Jordan 230 V 50 Hz C / D / F / G / J
Kazakhstan 220 V 50 Hz C / F
Kenya 240 V 50 Hz G
Kiribati 240 V 50 Hz I
South Korea, North 220 V 50 Hz C
South Korea, South 220 V 60 Hz F
Kosovo 230 V 50 Hz C / F
Kuwait 240 V 50 Hz G
Kyrgyzstan 220 V 50 Hz C / F
Laos 230 V 50 Hz A / B / C / E / F
Latvia 230 V 50 Hz C / F
Lebanon 230 V 50 Hz C / D / G
Lesotho 220 V 50 Hz M
Liberia 120 V 60 Hz A / B / C / F
220 V
Libya 230 V 50 Hz C / L
Liechtenstein 230 V 50 Hz C / J
Lithuania 230 V 50 Hz C / F
Luxembourg 230 V 50 Hz C / F
Macao 220 V 50 Hz G
Macedonia, North 230 V 50 Hz C / F
Madagascar 220 V 50 Hz C / E
Madeira 230 V 50 Hz C / F
Malawi 230 V 50 Hz G
Malaysia 240 V 50 Hz G
Maldives 230 V 50 Hz C / D / G / J / K / L
Mali 220 V 50 Hz C / E
Malta 230 V 50 Hz G
Marshall Islands 120 V 60 Hz A / B
Martinique 220 V 50 Hz C / D / E
Mauritania 220 V 50 Hz C
Mauritius 230 V 50 Hz C / G
Mayotte 230 V 50 Hz C / E
Mexico 120 V 60 Hz A / B
Federated States of Micronesia 120 V 60 Hz A / B
Moldova 230 V 50 Hz C / F
Monaco 230 V 50 Hz C / E / F
Mongolia 230 V 50 Hz C / E
Montenegro 230 V 50 Hz C / F
Montserrat 230 V 60 Hz A / B
Morocco 220 V 50 Hz C / E
Mozambique 220 V 50 Hz C / F / M
Myanmar (formerly Myanmar) 230 V 50 Hz A / C / D / G / I
Namibia 220 V 50 Hz D / M
Nauru 240 V 50 Hz I
Nepal 230 V 50 Hz C / D / M
Netherlands 230 V 50 Hz C / F
New Caledonia 220 V 50 Hz C / F
new Zealand 230 V 50 Hz I
Nicaragua 120 V 60 Hz A / B
Niger 220 V 50 Hz C / D / E / F
Nigeria 230 V 50 Hz D / G
Niue 230 V 50 Hz I
Norfolk Island 230 V 50 Hz I
Northern Cyprus (unrecognized,   self-declared state) 230 V 50 Hz G
Northern Ireland 230 V 50 Hz G
North Korea 220 V 50 Hz C
North Macedonia 230 V 50 Hz C / F
Norway 230 V 50 Hz C / F
Oman 240 V 50 Hz G
Pakistan 230 V 50 Hz C / D
Palau 120 V 60 Hz A / B
Palestine 230 V 50 Hz C / H
Panama 120 V 60 Hz A / B
Papua New Guinea 240 V 50 Hz I
Paraguay 220 V 50 Hz C
Peru 220 V 60 Hz A / C
Philippines 220 V 60 Hz A / B / C
Pitcairn Islands 230 V 50 Hz I
Poland 230 V 50 Hz C / E
Portugal 230 V 50 Hz C / F
Puerto Rico 120 V 60 Hz A / B
Qatar 240 V 50 Hz G
reunion 230 V 50 Hz C / E
Romania 230 V 50 Hz C / F
Russia (officially the Russian   Federation) 220 V 50 Hz C / F
Rwanda 230 V 50 Hz C / E / F / G
Saba 110 V 60 Hz A / B
Saint Barthelemy (also informally   known as Saint Barthes or Saint Barthes) 230 V 60 Hz C / E
Saint Kitts and Nevis (officially   the Federation of Saint Christopher and Nevis) 230 V 60 Hz D / G
Saint Lucia 230 V 50 Hz G
Saint Martin 220 V 60 Hz C / E
St. Helena 230 V 50 Hz G
Sint Eustatius 110 V 60 Hz A / B / C / F
220 V
Saint Martin 110 V 60 Hz A / B
Saint Vincent and the   Grenadines 110 V 50 Hz A / B / G
230 V
Samoa 230 V 50 Hz I
San Marino 230 V 50 Hz C / F / L
Sao Tome and Principe 230 V 50 Hz C / F
Saudi Arabia 220 V 60 Hz G
Scotland 230 V 50 Hz G
Senegal 230 V 50 Hz C / D / E / K
Serbia 230 V 50 Hz C / F
Seychelles 240 V 50 Hz G
Sierra Leone 230 V 50 Hz D / G
Singapore 230 V 50 Hz G
Slovakia 230 V 50 Hz C / E
Slovenia 230 V 50 Hz C / F
Solomon Islands 230 V 50 Hz G / I
Somalia 220 V 50 Hz C
Somaliland 220 V 50 Hz G
South Africa 230 V 50 Hz C / M / N (still rare)
Korea 220 V 60 Hz F
South Sudan 230 V 50 Hz C / D
Spain 230 V 50 Hz C / F
Sri Lanka 230 V 50 Hz D / G
Sudan 230 V 50 Hz C / D
Suriname 127 V 60 Hz A / B / C / F
220 V
Swaziland 230 V 50 Hz M
Sweden 230 V 50 Hz C / F
Switzerland 230 V 50 Hz C / J
Syria 220 V 50 Hz C / E / L
Tahiti 220 V 50 Hz / 60 Hz C / E
Taiwan 110 V 60 Hz A / B
Tajikistan 220 V 50 Hz C / F
Tanzania 230 V 50 Hz D / G
Thailand 230 V 50 Hz A / B / C / O
Togo 220 V 50 Hz C
Tokelau 230 V 50 Hz I
Tonga 240 V 50 Hz I
Trinidad and Tobago 115 V 60 Hz A / B
Tunisia 230 V 50 Hz C / E
Turkey 230 V 50 Hz C / F
Turkmenistan 220 V 50 Hz C / F
Turks and Caicos Islands 120 V 60 Hz A / B
Tuvalu 230 V 50 Hz I
Uganda 240 V 50 Hz G
Ukraine 230 V 50 Hz C / F
United Arab Emirates (UAE) 230 V 50 Hz G
United Kingdom (UK) 230 V 50 Hz G
United States of America (USA) 120 V 60 Hz A / B
United States Virgin Islands 110 V 60 Hz A / B
Uruguay 220 V 50 Hz C / F / L
Uzbekistan 220 V 50 Hz C / F
Vanuatu 230 V 50 Hz I
Vatican City 230 V 50 Hz C / F / L
Venezuela 120 V 60 Hz A / B
Vietnam 220 V 50 Hz A / B / C
Virgin Islands (British) 110 V 60 Hz A / B
Virgin Islands (United States) 110 V 60 Hz A / B
Wales 230 V 50 Hz G
Western Sahara 220 V 50 Hz C / E
Yemen 230 V 50 Hz A / D / G
Zambia 230 V 50 Hz C / D / G
Zimbabwe 240 V 50 Hz D / G
